Workstation
- 5th/4th Gen Intel® Xeon® Scalable processors, Single Socket LGA-4677 (Socket E), CPU TDP supports up to 350W TDP
- Intel C741® Chipset
- Up to 2TB 3DS ECC RDIMM, DDR5-5600MT/s (1DPC) in 8 DIMM slots
- 2 MCIO (PCIe5.0 x8) connectors for 4 NVMe SSDs
- 3 PCIe 5.0 x8,
2 PCIe 5.0 x16,
M.2 Interface: 2 PCIe 5.0 x4
M.2 Form Factor: 2280, 22110
M.2 Key: M-Key - Dual LAN with 1GbE with Intel® I210
- 4 USB 3.2 Gen1 (2 rear, 1 Type-A, 1 via header), 2 USB 2.0 (2 rear)
- Intel® C741 controller for 10 SATA3 (6 Gbps) ports
Specification
System
CPU
5th Gen Intel® Xeon® / 4th Gen Intel® Xeon® Scalable processors
Single Socket LGA-4677 (Socket E) supported, CPU TDP supports Up to 350W TDP
*BIOS 2.1 or above is required to support 5th Gen Intel® Xeon® Scalable processors
Chipset
Intel® C741
System Memory
8 DIMM slots
Up to 2TB 3DS ECC RDIMM, DDR5-5600MHz
**24GB & 48GB DIMM only support 1 DPC.
*24GB/48GB/96GB DDR5 DIMMs with 24Gb chip are only supported by 5th and 4th XCC Gen Intel® Xeon-SP CPU.
BIOS
AMI UEFI
Graphic
1 Aspeed AST2600 BMC port(s)
Expansion Slot
2 PCIe 5.0 x16,
3 PCIe 5.0 x8,
2 PCIe 5.0 x8 PCIe5.0 MCIO connector
–
M.2 Interface: 2 PCIe 5.0 x4
Form Factor: 2280/22110
Key: M-Key
Form Factor
EATX
Dimension
12.3″ x 10.1″ (31.24cm x 25.65cm)
I/O Interface
Display
1 VGA D-Sub Connector port(s)
Storage
Intel® C741 controller for 10 SATA3 (6 Gbps) ports; RAID 0,1,5,10
Ethernet
Dual LAN with 1GbE with Intel® I210
Audio
N/A
USB
2 USB 2.0 port(s) (2 rear)
4 USB 3.2 Gen1 port(s) (2 rear; 1 via header; 1 type A)
Internal USB Port
1 USB 3.2 Gen1 port (Type-A)
Serial
1 COM Port(s) (1 header)
PS/2 Port
N/A
TPM
1 TPM Header
*規格如有變更,恕不另行通知。
