Workstation
- Intel® Xeon® W-3400 series and Xeon® W-2400 series processors, TDP up to 350W
- Intel® W790
- Up to 2TB RDIMM 3DS, 512GB ECC RDIMM; DDR5-4800MT/s (1DPC)/4400MT/s (2DPC), in 8 DIMM slots
- 3 PCIe 5.0 x16 Slots, support up to 3 Single Width/2 Double Width/2 Triple Width GPU cards
1 PCIe 4.0 x4 Slots - M.2 Interface: 2 PCIe 5.0 x4
M.2 Form Factor: 2280/22110
M.2 Key: M-Socket (w/o heat sink) - 1GbE LAN port with Intel® Ethernet Controller I210-AT
10GbE LAN with Marvell AQC113 - 6 SATA 3 (6Gb, RAID 0, 1, 5, 10)
- IPMI Supported
- Overclocking Supported (optional)
Specification
System
CPU
Intel® Xeon® W-3400 series and Xeon® W-2400 series processors
Single Socket LGA-4677 (Socket E) supported, CPU TDP supports Up to 350W TDP
** Support CPU overclocking (optional, processors model name with the X suffix)
Chipset
Intel® W790
System Memory
8 DIMM slots
Up to 2TB 3DS ECC Registered RDIMM, DDR5-4800MHz
BIOS
32MB SPI Flash with AMI BIOS
Graphic
ASPEED AST2600 BMC
Expansion Slot
1 PCIe 4.0 x4,
3 PCIe 5.0 x16
–
M.2 Interface: 2 PCIe 5.0 x4, RAID 0 & 1
Form Factor: 22110, 2280
Key: M-Key
Form Factor
CEB
Dimension
12″ x 10″ (30.48cm x 25.4cm)
I/O Interface
Display
1 VGA port(s) (IPMI only)
Storage
Intel® W790 controller for 6 SATA3 (6 Gbps) ports; RAID 0, 1, 5, 10
Ethernet
1GbE LAN port with Intel® Ethernet Controller I210-AT
10GbE LAN with Marvell AQC113
Audio
ALC 888S HD Audio 7.1
USB
2 USB 2.0 port(s) (2 via header)
2 USB 3.2 Gen. 1 port(s) (2 via header)
4 USB 3.2 Gen. 2 Port(s) (4 rear)
2 USB 3.2 Gen. 2×2 port(s) (1 via header type C; 1 rear type C)
Internal USB Port
1 USB 3.2 Gen. 2×2 Port (Type-C)
Serial
1 COM Port(s) (1 rear)
PS/2 Port
N/A
TPM
1 TPM Header
