Workstation
- Intel® Xeon® W-3400 series and Xeon® W-2400 series processors, Up to 350W TDP
- Intel® W790
- Up to 4TB(W-3400)/2TB(W-2400) 3DS ECC RDIMM, 1TB(W-3400)/512GB(W-2400) ECC RDIMM; DDR5-4800MT/s(1DPC)/ 4400MT/s(2DPC), in 16 DIMM slots
- M.2 Interface: 4 PCIe 5.0 x4
M.2 Form Factor: 2280/22110
M.2 Key: M-Socket (w/o heat sink) - Xeon® W-3400 Series Processors: 6 PCIe 5.0 x16 Slots, support up to 6 Single Width/4 Double Width/2 Triple Width GPU cards Xeon® W-2400 Series Processors:3 PCIe 5.0 x16 Slots, support up to 3 Single Width/3 Double Width/2 Triple Width GPU cards (slot 3/5/7)
- 2 U.2 PCIe 3.0 for NVMe 2.5″ SSD drives (U.2-1, U.2-2)
- 1GbE LAN port with Intel® Ethernet Controller I210-AT
10GbE LAN with Marvell AQC113C - 8 SATA 3 (6Gb, RAID 0, 1, 5, 10)
- IPMI Supported
- Overclocking Supported (optional)
Specification
System
CPU
Intel® Xeon® W-3400 series and Xeon® W-2400 series processors
Single Socket LGA-4677 (Socket E) supported, CPU TDP supports Up to 350W TDP
** Support CPU overclocking (optional, processors model name with the X suffix)
Chipset
Intel® W790
System Memory
16 DIMM slots
Up to 4TB 3DS ECC Registered RDIMM, DDR5-4800MHz
BIOS
32MB SPI Flash with AMI BIOS
Graphic
ASPEED AST2600 BMC
Expansion Slot
6 PCIe 5.0 x16
–
M.2 Interface: 4 PCIe 5.0 x4, RAID 0, 1, 5, 10
Form Factor: 22110, 2280
Key: M-Key
Form Factor
E-ATX
Dimension
13″ x 12″ (33.02cm x 30.48cm)
I/O Interface
Display
1 VGA port(s) (IPMI only)
Storage
Intel® W790 controller for 8 SATA3 (6 Gbps) ports; RAID 0, 1, 5, 10
Ethernet
1GbE LAN port with Intel® Ethernet Controller I210-AT
10GbE LAN with Marvell AQC113C
Audio
ALC 888S HD Audio 7.1
USB
4 USB 2.0 port(s) (2 via header; 2 rear)
2 USB 3.2 Gen. 1 port(s) (2 via header)
4 USB 3.2 Gen. 2×1 Port(s) (4 rear)
2 USB 3.2 Gen. 2×2 port(s) (1 via header type C; 1 rear type C)
Internal USB Port
1 USB 3.2 Gen. 2×2 Port (Type-C)
Serial
1 COM Port(s) (1 rear)
PS/2 Port
N/A
TPM
1 TPM Header
*規格如有變更，恕不另行通知。
