Workstation
- 3rd Gen Intel® Xeon® Scalable processors, Single Socket LGA-4189 (Socket P+) supported, CPU TDP supports Up to 270W TDP
- Intel® C621A
- Up to 2TB 3DS ECC RDIMM, DDR4-3200MHz; Up to 2TB 3DS ECC LRDIMM, DDR4-3200MHz
Up to 2TB Intel® Optane™ Persistent Memory, in 8 DIMM slots - 2 PCIe 4.0 x8,
1 PCIe 4.0 x16,
1 PCIe 4.0 x8 (in x16 slot)
3 PCIe 3.0 x8
M.2 Interface: 1 SATA/PCIe 3.0 x4
M.2 Form Factor: 2280/22110
M.2 Key: M-Key - Intel® C621A controller for 10 SATA3 (6 Gbps) ports; RAID 0,1,5,10
- Dual LAN with Intel® i210 Gigabit Ethernet Controller
Specification
System
CPU
3rd Gen Intel® Xeon® Scalable processors
Single Socket LGA-4189 (Socket P+) supported, CPU TDP supports Up to 270W TDP
Chipset
Intel® C621A
System Memory
8 DIMM slots
Up to 2TB Intel® Optane™ Persistent Memory 200 Series
Up to 2TB 3DS ECC LRDIMM, DDR4-3200MHz; Up to 2TB 3DS ECC RDIMM, DDR4-3200MHz
BIOS
AMI UEFI
Graphic
1 ASPEED AST2600 BMC port(s)
Expansion Slot
1 PCIe 4.0 x16,
1 PCIe 4.0 x8 (in x16 slot),
2 PCIe 4.0 x8,
3 PCIe 3.0 x8
–
M.2 Interface: 1 SATA/PCIe 3.0 x4
Form Factor: 2280/22110
Key: M-Key
Form Factor
ATX
Dimension
12.1″ x 10″ (30.73cm x 25.4cm)
I/O Interface
Display
1 VGA port(s)
Storage
Intel® C621A controller for 10 SATA3 (6 Gbps) ports; RAID 0,1,5,10
Ethernet
Dual LAN with Intel® i210 Gigabit Ethernet Controller
Audio
USB
6 USB 2.0 port(s) (4 via header; 2 rear)
5 USB 3.2 Gen1 port(s) (2 via header; 2 rear; 1 type A)
Internal USB Port
1 USB 3.0
Serial
1 COM Port(s) (1 header)
PS/2 Port
N/A
TPM
1 TPM Header
*規格如有變更,恕不另行通知。
