WI-X11SPA-T

Workstation
  • 2nd Gen Intel® Xeon® Scalable Processors and Intel® Xeon® Scalable Processors, Intel® Xeon® W-32xx Processor
    Single Socket LGA-3647 (Socket P) supported, CPU TDP supports Up to 205W TDP
  • Up to 3TB 3DS ECC RDIMM, DDR4-2933MHz; Up to 2TB 3DS ECC LRDIMM, DDR4-2933MHz
    Up to 3TB Intel® Optane™ Persistent Memory, DDR4-2666MHz, in 12 DIMM slots;
    Xeon-W 32xx supports up to 2TB 3DS ECC RDIMM/LRDIMM, Xeon-W 32xx supports up to 1TB 3DS RDIMM/LRDIMM. _x000D_ ;
    Xeon-W32xx series processors don’t support DCPMM.
  • Intel® C621
  • 4 PCIe 3.0 x16,
    3 PCIe 3.0 x8 (in x16 slot),
    PCIex16 Slot#1 shares with M.2, Slot#2 shares with Slot#3(NA/16,8/8), Slot#4 shares with Slot#5(NA/16,8/8), Slot#6 shares with Slot#7(NA/16,8/8)
    (16/NA/16/NA/16/NA/16 or 16/8/8/8/8/8/8)
    M.2 Interface: 4 PCIe 3.0 x4, RAID 0 & 1
    M.2 Form Factor: 2242/2260/2280/22110
    M.2 Key: M-Key
    M.2 support RAID 0,1(up to RAID 5, 10), VROC key is required for Raid.
  • Intel® C621 controller for 8 SATA3 (6 Gbps) ports; RAID 0,1,5,10
  • Single LAN with Intel® Ethernet Controller I210-AT
    Single LAN with Aquantia® AQC107 10G Ethernet Controller
    Single LAN with Realtek RTL8211E PHY (dedicated IPMI)
  • 1 VGA port,
    VGA connector is dedicated for IPMI.
Specification
System
CPU

2nd Gen Intel® Xeon® Scalable Processors and Intel® Xeon® Scalable Processors, Intel® Xeon® W-32xx Processor

Single Socket LGA-3647 (Socket P) supported, CPU TDP supports Up to 205W TDP

Chipset
Intel® C621
System Memory

12 DIMM slots

Up to 3TB Intel® Optane™ Persistent Memory 200 Series, DDR4-2666MHz

Up to 2TB 3DS ECC LRDIMM, DDR4-2933MHz; Up to 3TB 3DS ECC RDIMM, DDR4-2933MHz

Xeon-W 32xx supports up to 2TB 3DS ECC RDIMM/LRDIMM, Xeon-W 32xx supports up to 1TB 3DS RDIMM/LRDIMM.

Xeon-W32xx series processors don’t support DCPMM.

BIOS
256MB SPI Flash with AMI BIOS
Graphic

1 ASPEED AST2500 BMC port(s)

VGA connector is dedicated for IPMI.

Expansion Slot

4 PCIe 3.0 x16,

3 PCIe 3.0 x8 (in x16 slot),

PCIex16 Slot#1 shares with M.2,
Slot#2 shares with Slot#3(NA/16,8/8),
Slot#4 shares with Slot#5(NA/16,8/8),
Slot#6 shares with Slot#7(NA/16,8/8)
(16/NA/16/NA/16/NA/16 or 16/8/8/8/8/8/8)
(16/NA/16/NA/16/NA/16 or 16/8/8/8/8/8/8)


M.2 Interface: 4 PCIe 3.0 x4, RAID 0 & 1

Form Factor: 2242/2260/2280/22110

Key: M-Key

M.2 support RAID 0,1(up to RAID 5, 10), VROC key is required for Raid.

Mini Type Slot
N/A
Power type
E-ATX
Dimension
12″ x 13″ (30.48cm x 33.02cm)
I/O Interface
Display
1 VGA port(s)
Storage
Intel® C621 controller for 8 SATA3 (6 Gbps) ports; RAID 0,1,5,10
Ethernet

Single LAN with Intel® Ethernet Controller I210-AT

Single LAN with Realtek RTL8211E PHY (dedicated IPMI)

Single LAN with Aquantia® AQC107 10G Ethernet Controller

Audio
ALC 888S HD Audio
USB

6 USB 3.1 Gen1 port(s) (2 via header; 4 rear type A)

2 USB 2.0 port(s) (2 via header)

4 USB 3.1 Gen2 port(s) (1 rear type C; 1 type A; 1 rear type A; 1 type C)

Internal USB Port
1 USB 3.0
Serial
2 COM Port(s) (1 header; 1 rear)
PS/2 Port
N/A
TPM
1 TPM Header
SMBus
Digital I/O
