12″ x 10″
- 2nd Gen Intel® Xeon® Scalable Processors and Intel® Xeon® Scalable Processors,
Dual Socket LGA-3647 (Socket P) supported, CPU TDP support Up to 140W TDP, 2 UPI up to 10.4 GT/s - Intel® C621
- Up to 2TB 3DS ECC RDIMM, DDR4-2933MHz; Up to 2TB 3DS ECC LRDIMM, DDR4-2933MHz, in 8 DIMM slots
- 2 PCIe 3.0 x16,
3 PCIe 3.0 x8,
1 PCIe 3.0 x4 (in x8 slot)
M.2 Interface: 1 SATA/PCIe 3.0 x4
M.2 Form Factor: 2260, 2280
M.2 Key: M-Key - Intel® C621 controller for 10 SATA3 (6 Gbps) ports; RAID 0,1,5,10
- Dual LAN with 1GbE with Intel® X722 + Marvell 88E1512
- 1 VGA port
Specification
System
CPU
2nd Gen Intel® Xeon® Scalable Processors and Intel® Xeon® Scalable Processors
Dual Socket LGA-3647 (Socket P) supported, CPU TDP supports Up to 140W TDP, Dual UPI up to 10.4 GT/s
Chipset
Intel® C621
System Memory
8 DIMM slots
Up to 2TB 3DS ECC LRDIMM, DDR4-2933MHz; Up to 2TB 3DS ECC RDIMM, DDR4-2933MHz
BIOS
AMI UEFI
Graphic
1 ASPEED AST2500 BMC port(s)
Expansion Slot
2 PCIe 3.0 x16,
3 PCIe 3.0 x8,
1 PCIe 3.0 x4 (in x8 slot)
–
M.2 Interface: 1 SATA/PCIe 3.0 x4
Form Factor: 2280, 2260
Key: M-Key
Form Factor
ATX
Dimension
12.076″ x 10.15″ (30.67cm x 25.78cm)
I/O Interface
Display
1 VGA port(s)
Storage
Intel® C621 controller for 10 SATA3 (6 Gbps) ports; RAID 0,1,5,10
Ethernet
Dual LAN with 1GbE with Intel® X722 + Marvell 88E1512
Audio
N/A
USB
4 USB 2.0 port(s) (2 rear + 2 via header)
3 USB 3.2 Gen1 port(s) (2 via header + 1 type A)
Internal USB Port
1 USB 3.0
Serial
1 COM Port(s) (1 header)
PS/2 Port
N/A
TPM
1 TPM Header
