WI-X11DPX-T

11 PCI-E Slots | 3 UPI | Dual 10GbE
  • 2nd Gen Intel® Xeon® Scalable Processors and Intel® Xeon® Scalable Processors,
    Dual Socket LGA-3647 (Socket P) supported, CPU TDP support Up to 205W TDP, 3 UPI up to 10.4 GT/s
  • Intel® C621
  • Up to 4TB 3DS ECC RDIMM, DDR4-2933MHz; Up to 4TB 3DS ECC LRDIMM, DDR4-2933MHz
    Or 2TB DCPMM, DDR4-2666MHz, in 16 DIMM slots;
    Up to 2TB Intel® Optane™ DC Persistent Memory in memory mode (Cascade Lake only).
  • 2 PCIe 3.0 x16,
    8 PCIe 3.0 x8,
    1 PCIe 3.0 x4 (in x8 slot) Or 4 PCIe 3.0 x16 and 4 PCIe 3.0 x8 and 1 PCIe 3.0 x4 (in x8 slot)
    M.2 Interface: 1 PCIe 3.0 x4
    M.2 Form Factor: 2280, 22110
    M.2 Key: M-Key
  • Dual LAN with Intel® X550 10GBase-T Ethernet Controller
  • Intel® C621 controller for 10 SATA3 (6 Gbps) ports; RAID 0,1,5,10
  • 1 VGA D-Sub Connector port
Specification
System
CPU

2nd Gen Intel® Xeon® Scalable Processors and Intel® Xeon® Scalable Processors

Dual Socket LGA-3647 (Socket P) supported, CPU TDP supports Up to 205W TDP, 3 UPI up to 10.4 GT/s

Chipset
Intel® C621
System Memory

16 DIMM slots
Up to 2TB Intel® Optane™ Persistent Memory 200 Series, DDR4-2666MHz
Up to 4TB 3DS ECC LRDIMM, DDR4-2933MHz; Up to 4TB 3DS ECC RDIMM, DDR4-2933MHz

Up to 2TB Intel® Optane™ DC Persistent Memory in memory mode (Cascade Lake only).

BIOS
32MB AMI SPI Flash ROM
Graphic
1 ASPEED AST2500 BMC port(s)
Expansion Slot

2 PCIe 3.0 x16,

8 PCIe 3.0 x8,

1 PCIe 3.0 x4 (in x8 slot) Or 4 PCIe 3.0 x16 and 4 PCIe 3.0 x8 and 1 PCIe 3.0 x4 (in x8 slot)

M.2 Interface: 1 PCIe 3.0 x4

Form Factor: 2280, 22110

Key: M-Key

Mini Type Slot
N/A
Power type
Proprietary
Dimension
15.12″ x 13.2″ (38.4cm x 33.53cm)
I/O Interface
Display
1 VGA D-Sub Connector port(s)
Storage
Intel® C621 controller for 10 SATA3 (6 Gbps) ports; RAID 0,1,5,10
Ethernet
Dual LAN with Intel® X550 10GBase-T Ethernet Controller
Audio
N/A
USB

4 USB 2.0 port(s) (2 rear; 2 via header)

3 USB 3.2 Gen1 port(s) (2 via header; 1 type A)

2 USB 3.0 port(s) (2 rear)

Internal USB Port
1 USB 3.0
Serial
2 COM Port(s) (1 header; 1 rear)
PS/2 Port
N/A
TPM
1 TPM Header
SMBus
Digital I/O
*規格如有變更,恕不另行通知。
