WI-X10DRW-i

16 DIMMs | 2400MHz DDR4 | WIO
  • Dual socket R3 (LGA 2011) supports Intel® Xeon® processor E5-2600 v4†/ v3 family; UPI up to 9.6GT/s
  • Intel® C612
  • Up to 2TB† ECC 3DS LRDIMM , up to DDR4- 2400†MHz ; 16x DIMM slots
  • Riser card support:
    Left side – 1 PCI-E 3.0 x32
    Right side – 1 PCI-E 3.0 x16
  • Intel® i350 Dual port GbE LAN
  • 10 SATA3 (6Gbps); RAID 0, 1, 5, 10
  • Integrated IPMI 2.0 and KVM with Dedicated LAN
  • 6 USB 3.0 (4 rear, 2 via header)
Specification
Product SKUs – Discontinued SKU (EOL). Please contact sales-rep for replacement SKUs.
System
CPU
Intel® Xeon® processor E5-2600 v3, Intel® Xeon® processor E5-2600 v4. Dual Socket R3 (LGA 2011) supported, CPU TDP support Up to 145W, 1 QPI up to 9.6GT/s
Chipset
Intel® C612
System Memory
Up to 1TB 3DS ECC RDIMM, DDR4-2400MHz; Up to 2TB 3DS ECC LRDIMM, in 16 DIMM slots
BIOS
128Mb SPI Flash EEPROM with AMI BIOS
Graphic
Aspeed AST2400 BMC
Expansion Slot

1x PCI-E 3.0 x16 for Add-on Module (AOM)

Riser card support:
Left side – 1 PCI-E 3.0 x32
Right side – 1 PCI-E 3.0 x16

Mini Type Slot
N/A
Power type
Proprietary WIO
Dimension
12.3″ x 13″ (31.24cm x 33.02cm)
I/O Interface
Display
1 VGA port
Storage
Intel® C612 controller for 10 SATA3 (6 Gbps) ports; RAID 0,1,5,10
Ethernet

Dual LAN with Intel® i350 Gigabit Ethernet Controller
Single LAN with Virtual Machine Device Queues reduce I/O overhead

Single LAN with Supports 10Base-T, 100BASE-TX, and 1000BASE-T, RJ45 output

Single LAN with 1 Realtek RTL8211E PHY (dedicated IPMI)

Audio
N/A
USB
6 USB 3.0 ports (4 rear + 2 headers)
Internal USB Port
N/A
Serial
1 COM Port (1 header)
PS/2 Port
N/A
TPM
1 TPM Header
SMBus
Digital I/O
