WI-X10DRH-I

16 DIMMs 12″ x 13″
  • Dual socket R3 (LGA 2011) supports Intel® Xeon® processor E5-2600 v4†/ v3 family; UPI up to 9.6GT/s
  • Intel® C612
  • Up to 2TB† ECC 3DS LRDIMM, up to DDR4- 2400†MHz; 16 DIMM slots
  • 1 PCI-E 3.0 x16,
    6 PCI-E 3.0 x8 slots
  • Intel® i350 Dual port GbE LAN
  • 10 SATA3 (6Gbps) ports w/ Intel® C612 controller; RAID 0, 1, 5, 10
  • Integrated IPMI 2.0 and KVM with Dedicated LAN
  • 5 USB 3.0 and 4 USB 2.0 ports
Specification
Product SKUs – Discontinued SKU (EOL). Please contact sales-rep for replacement SKUs.
System
CPU

Intel® Xeon® processor E5-2600 v3,
Intel® Xeon® processor E5-2600 v4.

Dual Socket R3 (LGA 2011) supported, CPU TDP support Up to 145W

Chipset
Intel® C612
System Memory

1TB Registered ECC RDIMM, DDR4-2133MHz; Up to 2TB 3DS ECC LRDIMM, in 16 DIMM slots

BIOS
128Mb SPI Flash EEPROM with AMI BIOS
Graphic
Aspeed AST2400 BMC
Expansion Slot

1 PCI-E 3.0 x16,

6 PCI-E 3.0 x8

Mini Type Slot
N/A
Power type
E-ATX
Dimension
12″ x 13″ (30.48cm x 33.02cm)
I/O Interface
Display
1 VGA port
Storage
Intel® C612 controller for 6 SATA3 (6 Gbps) ports; RAID 0,1,5,10
Ethernet

Dual LAN with Intel® i350 Gigabit Ethernet Controller
Single LAN with Virtual Machine Device Queues reduce I/O overhead

Single LAN with Supports 10Base-T, 100BASE-TX, and 1000BASE-T, RJ45 output

Single LAN with 1 Realtek RTL8211E PHY (dedicated IPMI)

Audio
N/A
USB

4 USB 2.0 ports (2 rear + 2 headers)

5 USB 3.0 ports (2 rear + 2 headers + 1 Type A)

Internal USB Port
1 USB 3.0
Serial

2 COM Ports (1 rear, 1 header)

2 fast UART 16550 serial

PS/2 Port
N/A
TPM
1 TPM Header
SMBus
Digital I/O
