WI-X11SCA

Workstation
  • 8th/9th Gen Intel® Core™ i9/i7/i5/i3, Pentium® and Celeron® Processors, Intel® Xeon® E-2100 Processors, Intel® Xeon® E-2200 Processors, Single LGA-1151 (Socket H4), Up to 95W TDP
  • Intel® C246
  • Single LAN with Intel® Ethernet Controller I210-AT
    Single LAN with Intel® PHY I219LM LAN controller
    Support vPro
  • Up to 128GB Unbuffered ECC/non-ECC UDIMM, DDR4-2666MHz, in 4 DIMM slots
  • 1 PCIe 3.0 x4,
    1 PCIe 3.0 x1,
    2 PCIe 3.0×16 (NA/16 or 8/8)
    1 5V PCI 32bit
    M.2 Interface: 2 PCIe 3.0 x4
    M.2 Form Factor: 2242/2260/2280/22110
    M.2 Key: M-Key
    M.2#1 are shared with PCIe x4 slot, M.2#2 is shared with U.2
    U.2 Interface: 1 PCIe 3.0 x4
  • 1 HDMI port, 1 DVI – D port, 1 DP (DisplayPort) port,
    Intel UHD P630 graphic(For CPU Xeon E-21XXG/E-22XXG series only)
  • Intel® C246 controller for 8 SATA3 (6 Gbps) ports; RAID 0,1,5,10
Specification
System
CPU

Intel® Xeon® E-2100 Processor, Intel® Xeon® E-2200 Processor, 8th/9th Generation Intel® Core™ i9/Core™ i7/Core™ i5/Core™ i3/Pentium®/Celeron® Processor

Single Socket LGA-1151 (Socket H4) supported, CPU TDP supports Up to 95W TDP

Chipset
Intel® C246
System Memory
4 DIMM slots Up to 128GB Unbuffered ECC/non-ECC UDIMM, DDR4-2666MHz
BIOS
128MB UEFI
Graphic
Intel UHD P630 graphic(For CPU Xeon E-21XXG/E-22XXG series only)
Expansion Slot

1 PCIe 3.0 x 4,

1 PCIe 3.0 x 1,

2 PCIex16 slots are running at NA/16, or 8/8

1 – 5V PCI 32bit


M.2 Interface: 2 PCIe 3.0 x4

Form Factor: 2242/2260/2280/22110

Key: M-Key

M.2#1 are shared with PCIex4 slot,

M.2#2 is shared with U.2

Mini Type Slot
N/A
Power type
ATX
Dimension
12″ x 9.6″ (30.48cm x 24.38cm)
I/O Interface
Display
1 DP (DisplayPort) port(s), 1 HDMI port(s), 1 DVI – D port(s)
Storage
Intel® C246 controller for 8 SATA3 (6 Gbps) ports; RAID 0,1,5,10
Ethernet

Single LAN with Intel® PHY I219LM LAN controller

Single LAN with Intel® Ethernet Controller I210-AT, Support vPro

Audio
ALC 888S HD Audio
USB

4 USB 3.1 Gen1 port(s) (2 via header; 2 rear type A)

4 USB 3.1 Gen2 port(s) (1 via header; 1 rear type C; 1 type A; 1 rear type A)

2 USB 2.0 port(s) (2 via header)

Internal USB Port
1 USB 3.0
Serial
1 COM Port(s) (1 header)
PS/2 Port
N/A
TPM
1 TPM Header
SMBus
Digital I/O
