WI-X10SRA

Workstation
  • Single socket R3 (LGA 2011) supports
    Intel® Xeon® processor E5-2600 v4†/ v3, E5-1600 v4†/ v3, Core i7
  • Intel® C612
  • Up to 512GB ECC DDR4 2400†MHz LRDIMM or 128GB ECC/non-ECC UDIMM (available with Core i7 only); 8 DIMM slots
  • 4 PCI-E 3.0 16 (run at 16/16/NA/8 or 16/8/8/8), 2 PCI-E 2.0 1 (in x4)
  • Intel® i210-AT Dual port GbE LAN
  • 10 SATA3 (6Gbps)
  • 1 COM, 1 TPM
  • 8 USB 3.0 ports (6 rear + 2 via header)
  • HD Audio 7.1 channel connector by Realtek ALC1150
Specification
Product SKUs – Discontinued SKU (EOL). Please contact sales-rep for replacement SKUs.
System
CPU

Intel® Core™ i7 series,
Intel® Xeon® Processor E5-1600 v3,
Intel® Xeon® Processor E5-1600 v4,
Intel® Xeon® processor E5-2600 v3,
Intel® Xeon® processor E5-2600 v4

Single Socket LGA-2011-3 (Socket R3) supported, CPU TDP supports Up to 160W TDP

Chipset
Intel® C612
System Memory

Up to 256GB Registered ECC RDIMM; Up to 1TB 3DS ECC LRDIMM, DDR4-2400MHz

Or 128GB Unbuffered ECC/non-ECC UDIMM, in 8 DIMM slots

Up to 512GB ECC LRDIMM ;
UDIMM will be only available for Core i7 processors. ;
2400MHz is supported by E5 V4 processors with 2DPC of LRDIMM or 1DPC of RDIMM.;
8x 288-pin DDR4 DIMM slots

BIOS
128Mb SPI Flash EEPROM with AMI BIOS
Graphic
Expansion Slot

4 PCI-E 3.0 x16

2 PCI-E 2.0 x1 (in x4 slot),

4 PCI-E Gen3x16 slots are running at 16/16/NA/8 or 16/8/8/8

PCI-E Slot#1 (x4) and Slot#4 (x16) are disabled when an Intel Core i7-5820K is installed)

PCI-E Slot#1 (x4) and Slot#4 (x16) are disabled when an Intel Core i7-5820K is installed)

Mini Type Slot
N/A
Power type
ATX
Dimension
12″ x 9.6″ (30.48cm x 24.38cm)
I/O Interface
Display
Storage

Intel® C612 controller for SATA3 (6 Gbps) ports; RAID 0,1,5,10

Ethernet

Dual LAN with Intel® i210 Gigabit Ethernet Controller

Audio
ALC 1150 HD Audio
USB

8 USB 3.2 Gen1 ports (6 rear + 2 via headers);
4 USB3.0 ports could be upgraded to 4 USB3.1(10 Gb/s) ports (2 rear, 2 by header)(BOM option)

Internal USB Port
N/A
Serial
1 COM Port (1 header)
PS/2 Port
1 x PS/2 combo
TPM
TPM Header
SMBus
Digital I/O
