WI-X11SRL-F
- Intel® Xeon® W-2100 Processors, Intel® Xeon® W-2200 Processors, Single Socket LGA-2066 (Socket R4) supported, CPU TDP support Up to 165W TDP
- Intel® C422
- Up to 512GB ECC RDIMM, DDR4-2933MHz; Up to 1TB Registered ECC LRDIMM, DDR4-2933MHz, in 8 DIMM slots
- 3 PCI-E 3.0 x8,1 PCI-E 3.0 x16,1 PCI-E 3.0 x8 (in x16 slot),1 PCI-E 3.0 x4 (in x8 slot)M.2 Interface: 1 PCI-E 3.0 x4M.2 Form Factor: 2280/22110M.2 Key: M-KeyDouble Height Connector
- Dual LAN with Intel® i210 Gigabit Ethernet Controller
- Intel® C422 controller for 8 SATA3 (6 Gbps) ports; RAID 0,1,5,10
System
CPU
Intel® Xeon® W-2100 Processors, Intel® Xeon® W-2200 Processors
Single Socket LGA-2066 (Socket R4) supported, CPU TDP support Up to 165W TDP
Chipset
Intel® C422
System Memory
Up to 512GB ECC RDIMM, DDR4-2933MHz; Up to 1TB Registered ECC LRDIMM, DDR4-2933MHz, in 8 DIMM slots
BIOS
AMI UEFI
Graphic
Aspeed AST2500 BMC
Expansion Slot
PCI-E
- 3 PCI-E 3.0 x8,
- 1 PCI-E 3.0 x16,
- 1 PCI-E 3.0 x8 (in x16 slot),
- 1 PCI-E 3.0 x4 (in x8 slot)
M.2
- M.2 Interface: 1 PCI-E 3.0 x4
- Form Factor: 2280/22110
- Key: M-Key
- Double Height Connector
Mini Type Slot
N/A
Power type
ATX
Dimension
12″ x 9.6″ (30.48cm x 24.38cm)
I/O Interface
Display
1 VGA port
Storage
Intel® C422 controller for 8 SATA3 (6 Gbps) ports; RAID 0,1,5,10
Ethernet
Dual LAN with Intel® i210 Gigabit Ethernet Controller
Audio
N/A
USB
6 USB 2.0 ports (2 rear + 4 via headers)
5 USB 3.0 ports (2 rear + 2 via headers + 1 Type A)
Internal USB Port
1 USB 3.0
Serial
2 COM Ports (1 rear, 1 header)
PS/2 Port
N/A
TPM
TPM Header
SMBus
Digital I/O
*規格如有變更，恕不另行通知。
