WI-X11SPL-F

VROC support
  • 2nd Gen Intel® Xeon® Scalable Processors and Intel® Xeon® Scalable Processors, Single Socket LGA-3647 (Socket P) supported, CPU TDP supports Up to 165W TDP
  • Intel® C621
  • Up to 2TB 3DS ECC RDIMM, DDR4-2933MHz; Up to 2TB 3DS ECC LRDIMM, DDR4-2933MHz, in 8 DIMM slots;
    Up to 1TB Intel Optane DC Persistent Memory in memory mode (Cascade Lake Only)
  • Expansion slots:
    2 PCIe 3.0 x8 (in x16),
    4 PCIe 3.0 x8,
    1 PCIe 3.0 x4 (in x8)
  • M.2 NGFF connector
    M.2 Interface: PCIe 3.0 x4 and SATA
    Form Factor: 2280, 22110
    Key: M-Key
  • 2 GbE LAN ports
  • 8 SATA3 (6Gbps) ports
  • I/O: 1 VGA, 2 COM, TPM header
  • 2 SuperDOM with built-in power
  • 5 USB 3.0 (2 rear, 1 Type-A, 2 via header), 8 USB 2.0 (2 rear, 6 via headers)
Specification
System
CPU

2nd Gen Intel® Xeon® Scalable Processors and Intel® Xeon® Scalable Processors

Single Socket LGA-3647 (Socket P) supported, CPU TDP supports Up to 165W TDP

Chipset
Intel® C621
System Memory

8 DIMM slots

Up to 2TB 3DS ECC LRDIMM, DDR4-2933MHz; Up to 2TB 3DS ECC RDIMM, DDR4-2933MHz

Up to 1TB Intel Optane DC Persistent Memory in memory mode (Cascade Lake Only)

BIOS
AMI UEFI
Graphic
1 ASPEED AST2500 BMC port(s)
Expansion Slot

2 PCIe 3.0 x8 (in x16 slot),

4 PCIe 3.0 x8,

1 PCIe 3.0 x4 (in x8 slot)

M.2 Interface: PCIe 3.0 x4; SATA

Form Factor: 2280, 22110

Key: M-Key

Mini Type Slot
N/A
Power type
ATX
Dimension
12″ x 9.6″ (30.48cm x 24.38cm)
I/O Interface
Display
1 VGA port(s)
Storage
Intel® C621 controller for 8 SATA3 (6 Gbps) ports; RAID 0,1,5,10
Ethernet
Dual LAN with 1GbE with Intel® I210
Audio
N/A
USB

3 USB 3 port(s) (1 Type A; 2 via header)

8 USB 2.0 port(s) (2 rear; 6 via header)

2 USB 3.0 port(s) (2 rear)

Internal USB Port
1 USB 3.0
Serial
2 COM Port(s) (1 header; 1 rear)
PS/2 Port
N/A
TPM
1 TPM Header
SMBus
Digital I/O
