WI-X10SLA-F

Key Features

  • Single socket H3 (LGA 1150) supports
    Intel® Xeon® E3-1200 v3/v4, 4th gen.
    Core i3, Pentium, Celeron processors
  • Intel® C222 Express PCH
  • Up to 32GB DDR3 ECC 1600MHz UDIMMs in 4 sockets
  • Dual GbE LAN ports via Intel® i210AT
  • 2 SATA (6Gbps), 4 SATA (3Gbps)
  • 1 PCI-E 3.0 x16, 1 PCI-E 2.0 x4 (in x8), and 5 PCI-32 slots
  • 2 USB 3.0 (1 Type-A + 1 via header)
    6 USB 2.0 (4 rear + 2 via header)
  • Integrated IPMI 2.0 with KVM and Dedicated LAN
  • SATA DOM power connector support
Specification

Product SKUs – Discontinued SKU (EOL). Please contact sales-rep for replacement SKUs.

System

CPU

  • Intel® 4th Generation Core™ i3 series, Intel® Celeron®, Intel® Pentium®v, Intel® Xeon® processor E3-1200 v3, Intel® Xeon® Processor E3-1200 v4 series.
  • Single Socket LGA 1150 supported, CPU TDP support 85W

Chipset

Intel® C222 Express PCH

System Memory

  • Up to 32GB Unbuffered ECC UDIMM, in 4 DIMM slots
  • 4x 240-pin DDR3 DIMM sockets

BIOS

128Mb SPI Flash EEPROM with AMI BIOS

Graphic

Aspeed AST2400 BMC

Expansion Slot

PCI-E

  • 1 PCI-E 3.0 x16
  • 1 PCI-E 2.0 x4 (in x 8 slot) 5 – 5V PCI 32bit

Mini Type Slot

N/A

Power type

ATX

Dimension

12″ x 9.6″ (30.48cm x 24.38cm)

I/O Interface

Display

1 VGA D-Sub Connector port

Storage

  • SATA3 (6 Gbps) ports; RAID 0,1
  • SATA2 (3 Gbps) ports; RAID 0,1,5,10

Ethernet

Dual LAN with Intel® Ethernet Controller I210-ATVirtual Machine Device Queues reduce I/O overheadSupports 10Base-T, 100BASE-TX, and 1000BASE-T, RJ45 outputRealtek RTL8211E PHY (dedicated IPMI)

Audio

N/A

USB

  • 6 USB 2.0 ports (4 rear + 2 headers)
  • 2 USB 3.0 ports (1 header + 1 Type A)

Internal USB Port

1 USB 3.0

Serial

2 COM Ports (1 rear, 1 header)

PS/2 Port

N/A

TPM

TPM Header

SMBus

Digital I/O
